InstallingtheAirCleanerSystem
IMPORTANT
Leaksintheairltersystemwillallowdirttoenterintotheengine
andcancauseseriousenginedamage.Ensurethatalltheaircleaner
componentsareingoodconditionandareproperlysecuredduring
installation.
1.AssembletheaircleanersystemasshowninFigure22.
A.Iftheserviceindicatorandadapterwereremoved,installtheadapterand
serviceindicator(Figure23).Torquetheadapterto3.3to3.5N·m(29to
31in-lb).T orquetheserviceindicatorto1to1.2N·m(9to11in-lb).
g221636
Figure23
1.ServiceIndicator
4.Aircleanerassembly
2.Adapter5.Vacuatorvalve
3.Bracket
B.Ensurethatthevacuatorvalve(item5inFigure23)ispointeddown
afterinstallation.
2.Lowerthehoodandsecureitwiththelatches.
DieselEngine:ServiceandRepairs
Page4–8
Groundsmaster
®
3280-D/3320
05138SLRevB
