IT2200 Reader System with Multimode Capability Installation & Maintenance/Service Guide

6-14

Table 6-7 Self-Test Fail LED on Reader Logic Card Lights

Indication Action

SELF-TEST

FAIL LED on

reader logic

card lights

during startup

Data cable or RF module power supply failed. Open the RF

module and check for 24 VAC at terminals A and C. The voltage

should be 19.2V to 28.8 VAC or 16 to 28 VDC. If voltage setting

meets your requirements, test the data cable using a loopback

connector. If the cable is good, the RF module failed. Replace

the RF module.
