Table C-6 IT2611 RF Module Environmental Specifications
Physical Specifications
Table C-7 lists the physical specifications of the IT2611 RF Module.
Table C-7 IT2611 RF Module Physical Specifications
Housing Specifications
The RF module housing consists of the following components:
• Fiberglass enclosure
• Bulkhead Type N connectors for antenna connections
• Bulkhead circular waterproof connectors for power and interface
• Stainless steel mounting hardware
Internal RF module printed wiring assemblies mount into a half-size ISA card cage.
This card cage mounts into the fiberglass enclosure for final mounting. All interface
connectors to the RF module are made through the fiberglass enclosure wall in bulk-
head style.
AA3152 Universal Toll Antenna and
AA3153 Beacon Antenna
Because the specifications for the AA3152 and AA3153 antennas are similar, this sec-
tion covers both antennas.
• Operates in the location and monitoring service band (902 to 928 MHz)
• Optimum radiation pattern—Virtually no side or back lobes help confine antenna
coverage to a single lane.
Environment Specification
Shock 5 G ½-sine pulse, 10 ms duration, 3 axes
Vibration 1.0 G
rms
10 to 500 Hz
Operating temperature -20° to +55°C (-4° to +131°F)
Humidity 95% noncondensing
Specification Value
Size 33 x 35.6 x 21.6 cm (13 x 14 x 8.5 in)
Weight 11.34 kg (25 lb)
