TransCore Amtech IT2200 - Table D-12 IP Module I;O Connector

To Next Page

To Previous Page

Hardware Interfaces

D-17

36 RESERVED N/C Reserved for future applications

37 A1 Out Address line A1

38 DMAEND In/Out DMA termination (active low)

39 A2 Out Address line A2

40 ERROR_L In IP module error (active low)

41 A3 Out Address line A3

42 INTREQ0_L In Interrupt request 0 (active low)

43 A4 Out Address line A4

44 INTREQ1_L In Interrupt request 1 (active low)

45 A5 Out Address line A5

46 STROBE_L In/Out Function strobe (optional)

47 A6 Out Address line A6

48 ACK_L In Data acknowledge (active low)

49 RESERVED N/C Reserved for future applications

50 GND Out Ground

Table D-12 IP Module I/O Connector

Pin Signal I/O Description

1 RCV In UART receive

2XMT Out UART transmit

3 GND In/Out System ground

4 GND In/Out System ground

5 RF_XMIT_EN Out RF downlink power on

6 RF_RCV_EN Out RF uplink power on

7-50 Reserved N/C Reserved

Table D-11 IP Module Logic Interface Connector (continued)

Pin Signal In/Out Description
