Connector Pin-outs

E-19

Table E-12 shows the IT2611 RF Module power connector pin designations.

Table E-13 shows the IT2611 RF Module-to-antenna connectors.

Table E-12 RF Module Power

Pin Description

A 19- to 28-VAC or

16- to 28-VDC

C 19- to 28 VAC Return or

16- to 28-VDC Return

BN/A

Table E-13 RF Module-Antenna Connectors

Connector Type Description

J1 N Socket RF uplink (receive) antenna

J2 N Socket RF downlink (transmit) antenna

J3 N Socket Check tag antenna
