TransCore Amtech IT2200 - HW Diagnostics Port; Table E-9 Hardware Diagnostics Port Connector

IT2200 Reader System with Multimode Capability Installation & Maintenance/Service Guide
E-16
HW Diagnostics Port
Table E-9 shows the pinout of the HW diagnostics port connector. Signal I/O is with
respect to the reader logic card.
Table E-9 Hardware Diagnostics Port Connector
Pin Name Type Description
1 HDP_EN_L Input Enables output buffers
2 GND Output Ground
3 CONT_CW_INP Input Enable CW mode
4 VCC Output +5 VDC power
5 SWSIG0 Output SW controlled debug bit
6 SWSIG1 Output SW controlled debug bit
7 SWSIG2 Output SW controlled debug bit
8 SWSIG3 Output SW controlled debug bit
9 SWSIG4 Output SW controlled debug bit
10 SWSIG5 Output SW controlled debug bit
11 SWSIG6 Output SW controlled debug bit
12 SWSIG7 Output SW controlled debug bit
13 B_HDRDET_L Output Buffered tag data present
14 B_MOD Output Modulation - IT2000
15 B_DECINT_L Output Decoder interrupt
16 B_TDMINT_L Output TDM interrupt
171 B_MRESET_L Output 360 reset from any source
18 B_ISARES_L Output ISA command or HW reset
19 B_ISAIRQ_H Output IRQ to host
20 B_IRQISA_L Output IRQ from host
21 Reserved N/A Reserved
22 Reserved N/A N/A
232 B_IF_A Output IF Data A - IT2200
24 B_IF_B Output IF Data B - IT2200
25 B_IF_C Output IF Data C - IT2200
