General Purpose I/O Port (IT2020-004 Reader)

The connector is a 32-pin, 0.1-center dual-row header (2 by 16). This connector is for

future use only. Table D-4 shows the pin designations for the general purpose I/O con-

nector.

Table D-4 General Purpose I/O Connector

Hardware Diagnostic Port

The connector is a 34-pin, 0.1-center dual-row header (2 by 17). Signal I/O is with

respect to the ISA reader. Table D-5 shows the pin designations and descriptions for

the hardware diagnostic connector.

Pin Signal In/Out Description

1 EXT_INT+ In External interrupt input signal (IT2020-004

reader only)

2BIN1 In

2BIN2 In

3BIN3 In

4BIN4 In

5 BOUT4 Out

6 BOUT3 Out

7 BOUT2 Out

8 BOUT1 Out Good tag output signal (active low) (IT2020-

004 reader only)

9VCC
