IT2200 Reader System with Multimode Capability Installation & Maintenance/Service Guide
3-14
Features
This antenna is specifically designed for use in toll lane applications, and it transmits
and receives RF signals in the 902- to 928-MHz RF range. The AA3152 UTA
transmission pattern has virtually no side or back lobes, which helps to confine
antenna coverage to a single lane width. The antenna is enclosed in a weatherproof
radome, which is made of materials selected for favorable electrical characteristics
and resistance to ultraviolet radiation.
The AA3152 UTA is designed for outdoor use. The antenna operates without
performance degradation in hot or cold temperature extremes, strong wind, or
vibrations caused by passing vehicles.
AA3153 Beacon Antenna
The IT2200 Reader System with Multimode Capability uses either one or two
AA3153 Beacon Antennas for pillbox-type plaza installations.
Functions
In a monostatic configuration, the AA3153 Beacon Antenna acts as the downlink
antenna transmitting signals to the tag, and the uplink antenna receiving signals from a
vehicle tag. In a bistatic configuration, an AA3153 Antenna acts as the downlink
antenna transmitting signals to the tag, and another AA3153 Antenna acts as the
uplink antenna receiving signals from a vehicle tag.
Features
This antenna is specifically designed for use in toll lane applications, and transmits
and receives RF signals in the 902- to 928-MHz RF range. The AA3153Antenna
broadcast patter has virtually no side or back lobes, which helps to confine antenna
coverage to a single lane width. The antenna is enclosed in a weatherproof radome,
which is made of materials selected for favorable electrical characteristics and
resistance to ultraviolet radiation.
The beacon antenna is designed for outdoor use. The antenna operates without
performance degradation in hot or cold temperature extremes, strong wind, or
vibrations caused by passing vehicles.
IT2502 Check Tag Antenna
The IT2502 Check Tag Antenna is used to communicate with the check tag that is
located inside the RF module.
Check Tag
A check tag is a special-purpose tag that is integrated in the RF module and has a
separate check tag antenna.
