IT2200 Reader System with Multimode Capability Installation & Maintenance/Service Guide

E-14

BDM

The BDM (background debugger mode) connector is a 10-pin, 0.100 center, dual row

header with a 2 x 5 configuration.

Table E-7 shows the pinout of the BDM connector. Signal I/O is with respect to the

reader logic card.

Table E-7 BDM Connector

Pin Name Type Description

1 DS_L Input/

output

Data strobe

2 BERR_L Input/

output

Bus error

3 GND Input/

output

Ground

4 BKPT/DSCLK Input Development serial clock

5 GND Input/

output

Ground

6 FREEZE Output Breakpoint acknowledge

7 RESET_L Input/

output

Hard system reset

8 IFETCH/DSI Input Development serial input

9 VCC Input/

output

+5 VDC power

10 IPIPE0/DSO Output Development serial output
