Connector Pin-outs

E-17

RS-232

The RS-232 connector is a standard DB-9 plug. The pinout of this connector is such

that it does not need a null modem cable to connect to a PC serial port.

Table E-10 shows the pinout of the DB-25 connector. Signal I/O is with respect to the

reader logic card.

26 Reserved N/A N/A

27 Reserved N/A N/A

28 Reserved N/A N/A

29 BHW_IP_RXD Output Buffered RF module receive

30 BHW_IP_TXD Output Buffered RF module transmit

31 VCC Output +5 VDC power

32 VCC Output +5 VDC power

33 GND Output Ground

34 GND Output Ground

Table E-10 RS-232 Connector

Pin Name Type Description

1 RSD N/A Received line signal detect

2 TXD Output Transmit data

3 RXD Input Receive data

4 DTR N/A Data terminal ready

5 GND Input/

output

Ground

6 DSR N/A Data set ready

7 CTS Input Clear to send

8 RTS Output Request to send

9 RI N/A Ring indicator

Table E-9 Hardware Diagnostics Port Connector (continued)

Pin Name Type Description
