Connector Pin-outs
E-9
IP Module Logic Interface
Table E-4 shows the pinout of the IP module logic interface connector. Signal I/O is
with respect to the reader logic card.
Table E-4 IP Module Logic Interface Connector
Pin Name Type Description
1 GND Output Ground
2 CLK Output 8-MHz clock
3 RESET_L Output Reset signal (active low)
4 D0 Input/output Data bit 0
5 D1 Input/output Data bit 1
6 D2 Input/output Data bit 2
7 D3 Input/output Data bit 3
8 D4 Input/output Data bit 4
9 D5 Input/output Data bit 5
10 D6 Input/output Data bit 6
11 D7 Input/output Data bit 7
12 D8 Input/output Data bit 8
13 D9 Input/output Data bit 9
14 D10 Input/output Data bit 10
15 D11 Input/output Data bit 11
16 D12 Input/output Data bit 12
17 D13 Input/output Data bit 13
18 D14 Input/output Data bit 14
19 D15 Input/output Data bit 15
20 BS0_L Output Byte select 0 (active low)
21 BS1_L Output Byte select 1 (active low)
22 -12 V Output -12 volt power
23 +12 V Output +12 volt power
24 +5 VDC Output +5 volt power
25 GND Output Ground
