Hardware Interfaces
D-23
Table D-15 RF Module Power
Table D-16 shows the IT2611 RF Module-to-antenna connectors for bistatic operation
and Table D-17 shows the connectors for monostatic operation.
IT2410 Tag Programmer Hardware Interconnection
The IT2410 Tag Programmer requires only a small DC power supply and a DB-9
serial interface cable. Cabling for the two interconnections requires proper shielding
at both ends to meet Part 15 of FCC emission requirements.
The serial interface is RS-232 compatible. A null-modem adapter is required to con-
nect the programmer to RS-232 serial interfaces from most computers configured as
data terminal equipment (DTE). No hardware handshaking is employed; however,
handshaking is accomplished by firmware protocol as described in the interface defi-
nitions. Pin-outs of the RS-232 serial interface are shown in Table D-18.
Pin Description
A 19- to 28-VAC or
16- to 28-VDC
C 19- to 28 VAC Return or
16- to 28-VDC Return
B Not connected
Table D-16 RF Module-Antenna Connectors for Bistatic Operation
Connector Description Type
J1 RF uplink (receive) antenna N Socket
J2 RF downlink (transmit)
antenna
N Socket
J3 Check tag antenna N Socket
Table D-17 RF Module-Antenna Connectors for Monostatic Operation
Connector Description Type
J1 RF uplink/downlink (receive/
transmit) antenna
N Socket
J3 Check tag antenna N Socket
