Installing the IT2200 Reader System

4-17

Installing the IT2611 RF Module

The IT2611 RF Module should be mounted on a 5.0 to 7.6cm (2- to 3-in) pipe. A

mounting kit is provided with each RF module that includes:

• RF module

• Two U-bolts

• Two brackets

• Four spacers

• Eight nuts

• Four lock washers

• Shrink tubing

Figure 4-13 shows the correct way to mount the RF module.
