turck BL67 - Measurement Value Representation

Analog input modules
D300529 0115 - BL67 I/O modules6-14
6.2.6 Measurement value representation
16-bit-representation
 Current values from 0 to 20 mA
Th
e value range:
0
mA to 20 mA
is displa
yed as follows:
0
000
hex
bis 7FFF
hex
(decimal: 0 to 32767)
 Current values from 4 to 20 mA
The value range:
4 mA to 20 mA
is displayed as follows:
0000
hex
bis 7FFF
hex
(decimal: 0 to 32767)
12-bit-representation (left-justified)
 Current values from 0 to 20 mA
Th
e value range:
0
mA to 20 mA
is displa
yed as follows:
0
00(0)
hex
to FFF(0)
hex
(decimal: 0 to 4095)
 Current values from 4 to 20 mA
The value range:
4 mA to 20 mA
is displayed as follows:
000(0)
hex
to FFF(0)
hex
(decimal: 0 to 4095)
NO
TE
A detailed description of the measurement value representation for the analog input mod-
ules in 16 or 12 bit can be found in the Appendix of this manual, page 15-8.
