turck BL67 - Signal Assignment

D300529 0115 - BL67 I/O modules
9-15
BL67-4DI4DO-PD
9.2.6 Signal assignment
n = Offset of process input data; depending on extension of station and the corresponding fieldbus.
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
C = slot no.
P = pin no.
Sensor supply
Table 9-7:
Signal assignment
with
BL67-B-8M8
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
In n - - - - C3P4 C2P4 C1P4 C0P4
Out m - - - - C7P4 C6P4 C5P4 C4P4
Table 9-8:
Signal assignment
with
BL67-B-4M12
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
In n C3P4 C2P4 C1P4 C0P4
Out m C3P2 C2P2 C1P2 C0P2
Table 9-9:
Signal assignment
with
BL67-B-4M12-P
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
In n C1P2 C1P4 C0P4 C0P4
Out m C3P2 C3P4 C2P4 C2P4
Table 9-10:
Signal assignment
with
BL67-B-1M23-(VI)
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
In n C0P4 C0P3 C0P2 C0P1
Out m C0P8 C0P7 C0P6 C0P5
Table 9-11:
Sensor supply
V
sens
ABCD
BL67-B-8M8 C0P1/
C1P1
C2P1/
C3P1
C4P1/
C5P1
C6P1/
C7P1
BL67-B-4M12 C0P1 C1P1 C2P1 C3P1
BL67-B-4M12-P C0P1 C1P1 C2P1 C3P1
BL67-B-1M23-VI C0P9 C0P10 C0P11 -
