D300529 0115 - BL67 I/O modules
12-55
BL67-1CVI
12.4.2 Process data
The process data of the CVI-module mirror the data of the connected CANopen-nodes depending on
their parameterization (see Table 12-6: Configuration possibilities for the CANopen-nodes). The process
data begin with the data of the node
with the lowest address, followed by the data of all other modules
in chronological order. This applies to both, in- and output data.
NOTE
Isolation voltages
U
TMB
(module bus/field, CAN) max. 1000 VDC
U
field
(field/CAN) 0 VDC
U
field
(supply valve electronic/CAN)
0 VDC
U
field
(supply valves/CAN) 0 VDC
Short-circuit proof yes, according to EN 61131-2
The input data of not connected or disturbed CANopen-nodes are assumed as "0".
