BL67-4AI-V/I, voltage-/current measurement
6.6.4 Module parameters
NOTE
Due to a product actualization, the parameter texts of the TURCK-I/O-product have been
revised.
The actual configuration files (GSD-, GSDML-, EDS-files) with the new parameters can be
found under www.turck.com.
If you use older configuration files with old parameter texts (issue date before April 2014),
then you can find a cross reference list in the manual's appendix (see Cross reference list
parameters (page 15-30)).
Standard
PROFIBUS
PROFINET
Parameter
byte-
oriented
word-
oriented
Channel 0
Byte 0
Bit 0
Word 0
Bit 0
Byte 0
Bit 0 Measurement range
Bit 1 Bit 1 Bit 1 Data format
Bit 2 Bit 2 Bit 2 Deactivate diagnostics
Bit 3 Bit 3 Bit 3 Deactivate channel
Bit 4 Bit 4 Bit 4 Operation mode
Bit 5 Bit 5 Bit 5 Data representation
Bit 6 Bit 6 Bit 6
Bit 7 Bit 7 Bit 7 reserved
Channel 1
Byte 1
Bit 0 Bit 8
Byte 1
Bit 0 Measurement range
Bit 1 Bit 9 Bit 1 Data format
Bit 2 Bit 10 Bit 2 Deactivate diagnostics
Bit 3 Bit 11 Bit 3 Deactivate channel
Bit 4 Bit 12 Bit 4 Operation mode
Bit 5 Bit 13 Bit 5 Data representation
Bit 6 Bit 14 Bit 6
Bit 7 Bit 15 Bit 7 reserved
Channel 2
Byte 2
Bit 0
Word 1
Bit 0
Byte 0
Bit 0 Measurement range
Bit 1 Bit 1 Bit 1 Data format
Bit 2 Bit 2 Bit 2 Deactivate diagnostics
Bit 3 Bit 3 Bit 3 Deactivate channel
Bit 4 Bit 4 Bit 4 Operation mode
Bit 5 Bit 5 Bit 5 Data representation
Bit 6 Bit 6 Bit 6
Bit 7 Bit 7 Bit 7 reserved
Channel 3
Byte 3
Bit 0 Bit 8
Byte 1
Bit 0 Measurement range
Bit 1 Bit 9 Bit 1 Data format
Bit 2 Bit 10 Bit 2 Deactivate diagnostics
Bit 3 Bit 11 Bit 3 Deactivate channel
Bit 4 Bit 12 Bit 4 Operation mode
Bit 5 Bit 13 Bit 5 Data representation
Bit 6 Bit 14 Bit 6
Bit 7 Bit 15 Bit 7 reserved
