turck BL67 - Technical Features

Technology modules
D300529 0115 - BL67 I/O modules12-76
12.5.7 Technical features
Block diagram
Figure 12-40:
BL67-1CNT/ENC
Figure 12-41:
Block diagram
24 VDC
GND
4 x DO
24 V
0,5 A
4 x DI
24 V
GND
24 VDC
24 VDC
logic
galvanic isolation
signal processing for count
and measurement operations
sensor
supply
filter
direction detection
pulse controlling
sensor
supply
optional
24 VDC module bus supply 5 VDC module bus
field
