NOTE
Digital combi modules
D300
529 0115 - BL67 I/O modules9-20
9.3.2 Process data mapping
n = Offset of process input data; depending on extension of station and the corresponding fieldbus.
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
Proc
ess data Value Meaning
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Input n
XSG7 XSG6 XSG5 XSG4 XSG3 XSG2 XSG1 XSG0
Output m XSG7 XSG6 XSG5 XSG4 XSG3 XSG2 XSG1 XSG0
The status of a digital output is simultaneously displayed as input at the respective channel.
NOTE
With PROFIBUS, PROFINET and CANopen, the I/O data of this module is localized within the
process data of the whole
station via the hardware configuration tool of the fieldbus master.
For DeviceNet, EtherNet/IP and Modbus TCP a detailed mapping table can be created with
the TURCK configuration tool I/O-ASSISTANT V3 (PACTware + BL67-DTM).
Table 9-13:
Process data bits
DIx 0 Digital input inactive
1 Digita
l input active
DOx 0
Digita
l output inactive
1 Di
gital output active
