turck BL67 - Measurement Value Representation

NOTE
Analog output modules
D3
00529 0115 - BL67 I/O modules8-8
8.2.5 Measurement value representation
Standard value representation
 16-bit-representation
 12-bit-representation (left-justified)
Concerning the "number representation", please observe the tables for measurement value
representation on the following pages.
dec. hex. 0 … 20 mA 4 … 20 mA
dec. value = 1638,35 [1/mA] ×
current value
dec. value = 2047.94 ×
(current value [mA]- 4 mA)
32767 7FFF 20.0000 mA 20.0000 mA
32766 7FFE 19.9994 mA 19.9995 mA
…… … …
16384 4000 10.0003 mA 12.00024 mA
…… … …
1 0001 0.0006103 mA 4.0004883 mA
0 0000 0.000000 mA 4.000000 mA
-1 FFFF 0.000000 mA 4.000000 mA
…… … …
-16384 C000 0.000000 mA 4.000000 mA
…… … …
-32767 8001 0.000000 mA 4.000000 mA
-32768 8000 0.000000 mA 4.000000 mA
dec. hex. 0 … 20 mA 4 … 20 mA
dec. value = 204.75 [1/mA] × current
value [mA] × 16
dec. value = 255,9 [1/mA] × (current
value [mA] - 4 mA) × 16
4095 × 16 FFF× 20.0000 mA 20.0000 mA
4094 × 16 Flex 19.995117 mA 19.99609 mA
…… … …
2048 × 16 800× 10.0024 mA 12.0019 mA
…… … …
1 × 16 001× 0.004883 mA 4.00391 mA
0 000× 0.000000 mA 4.000000 mA
