D300529 0115 - BL67 I/O modules
5-27
BL67-8DI-PD
5.5.1 Technical data
5.5.2 Process data mapping
n = offset of input data; depending on extension of station and the corresponding fieldbus.
Process data Value Meaning
Table 5-27:
Technical data
Designation BL67-8DI-PD
No. of channels 8
Input voltage V
sens
at nominal value 24 VDC
Low level < 4,5 V
High level >
7 V (max.
30 V)
Nominal current consumption from 5 VDC (mod-
ule bus) I
MB
≤ 30 mA
Nominal current from supply terminal (field) I
L
≤ 100 mA (all inputs low)
Power loss of the module < 1,5 W
Input current I
in
Low level < 1,5 mA
High level >
3.
7 mA
Input delay
t
ON
< 2,5 ms
t
OFF
< 2,5 ms
Isolation voltage
U
TMB
(module bus/field) max. 2500 VDC
U
FE
max. 1000 VDC
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Input n
DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
NOTE
With PROFIBUS, PROFINET and CANopen, the I/O data of this module is localized within the
proce
ss data of the whole station via the hardware configuration tool of the fieldbus master.
For DeviceNet, EtherNet/IP and Modbus TCP a detailed mapping table can be created with
the TURCK configuration tool I/O-ASSISTANT V3 (PACTware + BL67-DTM).
Table 5-28:
Process data bits
DIx 0 Digital input inactive
1 Digita
l input active
