turck BL67 - Signal Assignment

Digital output modules
D300529 0115 - BL67 I/O modules7-28
7.4.6 Signal assignment
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
C = slot no.
P = pin no.
Table 7-24:
Signal assign-
ment with BL67-B-
4M8
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Out m - - - - C3P4 C2P4 C1P4 C0P4
Table 7-25:
Signal assign-
ment with BL67-B-
2M12
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Out m - - - - C1P2 C0P2 C1P4 C0P4
Table 7-26:
Signal assign-
ment with
BL67-B-2M12-P
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Out m - - - - C1P2 C1P4 C0P2 C0P4
Table 7-27:
Signal assign-
ment with BL67-B-
4M12
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Out m - - - - C3P4 C2P4 C1P4 C0P4
Table 7-28:
Signal assign-
ment with BL67-B-
1M23
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Out m - - - - C0P4 C0P3 C0P2 C0P1
