D300529 0115 - BL67 I/O modules
14-3
Designations/ident-no.
14.2 Designations/ident-no.
The designation is imprinted on the top of the electronic modules.
Each module is clearly identified by a Indent-number.
The Indent-number as well as further module-
specific details (pin assignment of the base modules, etc.) can be found on a label attached to the side
of the respective module.
Figure 14-1:
Figure 14-2:
Module label
labeling
A type designa-
tion
B diagnosis LED
C label for
application spe-
cific use
D channel-LEDs
