14.3 Channel numbering
Base module connections are numbered consecutively channel by channel.
Figure 14-3:
14.4 Labeling of the rotary coding switches
The labeling of the rotary coding switches for setting the field bus addresses can be found on the gate-
way side next to the protection cover.
Figure 14-4:
Channel
numbering
Gateway
labeling
