turck BL67 - Module Parameters

Digital combi modules
D300529 0115 - BL67 I/O modules9-10
9.2.4 Module parameters
NOTE
Due to a product actualization, the parameter texts of the TURCK-I/O-product have been
revised.
The actual configuration files (GSD-, GSDML-, EDS-files) with the new parameters can be
found under www.turck.com.
If you use older configuration files with old parameter texts (issue date before April 2014),
then you can find a cross reference list in the manual's appendix (see Cross reference list
parameters (page 15-30)).
Standard
PROFIBUS
PROFINET
Parameter
byte-
oriented
word-
oriented
Byte 0
Bit 0
Word 0
Bit 0
Byte 0
Bit 0 Activate input filter (channel 0)
Bit 1 Bit 1 Bit 1 Activate input filter (channel 1)
Bit 2 Bit 2 Bit 2 Activate input filter (channel 2)
Bit 3 Bit 3 Bit 3 Activate input filter (channel 3)
Bit 4 Bit 4 Bit 4 reserved
Bit 5Bit 5Bit 5
Bit 6Bit 6Bit 6
Bit 7Bit 7Bit 7
Byte 1
Bit 0 Bit 8
Byte 1
Bit 0 Invert digital input (channel 0)
Bit 1 Bit 9 Bit 1 Invert digital input (channel 1)
Bit 2 Bit 10 Bit 2 Invert digital input (channel 2)
Bit 3 Bit 11 Bit 3 Invert digital input (channel 3)
Bit 4 Bit 12 Bit 4 reserved
Bit 5 Bit 13 Bit 5
Bit 6 Bit 14 Bit 6
Bit 7 Bit 15 Bit 7
Byte 2
Bit 0
Word 1
Bit 0
Byte 2
Bit 0 Manual output reset after overcurrent
(channel 0)
Bit 1 Bit 1 Bit 1 Manual output reset after overcurrent
(channel 1)
Bit 2 Bit 2 Bit 2 Manual output reset after overcurrent
(channel 2)
Bit 3 Bit 3 Bit 3 Manual output reset after overcurrent
(channel 3)
Bit 4 Bit 4 Bit 4 reserved
Bit 5Bit 5Bit 5
Bit 6Bit 6Bit 6
Bit 7Bit 7Bit 7
Byte 3
Bit 0 Bit 8
Byte 3
Bit 0 reserved
Bit 1Bit 9Bit 1
Bit 2 Bit 10 Bit 2
Bit 3 Bit 11 Bit 3
Bit 4 Bit 12 Bit 4
Bit 5 Bit 13 Bit 5
Bit 6 Bit 14 Bit 6
Bit 7 Bit 15 Bit 7
