turck BL67 - Base Modules;Pin Assignment

Digital output modules
D300529 0115 - BL67 I/O modules7-42
7.6.5 Base modules/pin assignment
 BL67-B-1M23-19
Figure 7-52:
0
Figure 7-53:
v
19
11
12
1
2
3
4
5
6
7
8
9
10
18
13
14
15
16
17
1 = Output 14
2 = Output 10
3 = Output 6
4 = Output 3
5 = Output 2
6 = GND
7 = Output 1
8 = Output 5
9 = Output 9
10 = Output 13
11 = Output 12
12 = PE
13 = Output 11
14 = Output 7
15 = Output 0
16 = Output 4
17 = Output 8
18 = Output 15
19 = V
SENS
 BL67-B-8M8
Figure 7-54:
0
1
2
4
5
6
3
7
Figure 7-55:
1 = V
SENS
2 = Signal A
3 = GND
4 = Signal B
v
42
31
-4-P
BL67-B-1M23-19
Pin assignment
BL67-16DO-0.1A-P
with
BL67-B-1M23-19
BL67-B-8M8-4-P
Pin assignment
BL67-16DO-0.1A-P
with
BL67-B-8M8-4-P
