turck BL67 - Page 207

D300529 0115 - BL67 I/O modules
7-43
BL67-16DO-0.1A-P
Signal assignment
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
C = slot no.
P = pin no.
Table 7-42:
Signal assign-
ment with
BL67-B-1M23-19
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
Out
m C0P14 C0P3 C0P8 C0P16 C0P4 C0P5 C0P7 C0P15
m + 1 C0P18 C0P1 C0P10 C0P11 C0P13 C0P2 C0P9 C0P17
Table 7-43:
Signal assign-
ment with
BL67-B-8M8-4-P
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
Out
m C3P2 C3P4 C2P2 C2P4 C1P2 C1P4 C0P2 C0P4
m + 1 C7P2 C7P4 C6P2 C6P4 C5P2 C5P4 C4P2 C4P4
