turck BL67 - Base Modules;Pin Assignment

Digital output modules
D300529 0115 - BL67 I/O modules7-56
7.8.5 Base modules/pin assignment
 BL67-B-8M8
Figure 7-71:
0
1
2
4
5
6
3
7
Figure 7-72:
3
1
4
v
1 = V
SENS
3 = GND
4 = Output A
Figure 7-73:
BN
GND
4 ( ) BK
1 (+) BN
BL67-B-8M8
Pin assignment
BL67-8DO-0.5A-N
with BL67-B-8M8
Wiring diagram
BL67-8DO-0.5A-N
with BL67-B-8M8
