12.3.13 Base modules/pin assignment
 BL67-B-1M12-8
Figure 12-23:
0
Figure 12-24:
6
1
3
2
8
v
4
5
7
1 = GND
2 = V
SENS
3 = CLK +
4 = CLK 
5 = Data +
6 = Data 
7 = n.c.
8 = Schirm
 BL67-B-1M23
Figure 12-25:
0
/BL67-B-1M23-VI
Figure 12-26:
81
9
712102
54
63
11
v
1 = GND
2 = V
SENS
3 = CLK +
4 = CLK 
5 = Data +
6 = Data 
7 = n.c.
8 = Schirm
9 = n.c.
10 = n.c.
11 = n.c.
12 = n.c.
BL67-B-1M12-8
Pin assignment
B
L67-1SSI with
BL67-B-1M12-8
BL67-B-1M23/
B
L67-B-1M23-VI
Pin assignment
BL67-1SSI with
BL67-B-1M23
