D300529 0115 - BL67 I/O modules
6-25
BL67-2AI-PT, Pt-/Ni-sensors
6.4.2 Process data mapping
n = offset of input data; depending on extension of station and the corresponding fieldbus.
Process data Meaning
6.4.3 Diagnostic and status messages
LED status displays
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Input n AI0 LSB
n + 1 AI0 MSB
n + 2 AI1 LSB
n + 3 AI1 MSB
NOTE
With PROFIBUS, PROFINET and CANopen, the I/O data of this module is localized within the
proce
ss data of the whole station via the hardware configuration tool of the fieldbus master.
For DeviceNet, EtherNet/IP and Modbus TCP a detailed mapping table can be created with
the TURCK configuration tool I/O-ASSISTANT V3 (PACTware + BL67-DTM).
Table 6-14:
Process data bits
AI1 LSB low byte of the analog value
AIx MSB high byte of the analog value
Table 6-15:
LED status dis-
plays
LED Display Meaning Remedy
DRed,
flashing,
0.5 Hz
Diagnostics pending -
Red M
odule bus communication
failure
Check if more than two ad-joining
electronics modules have been
pulled. This concerns modules
located between this module and
the gateway.
OFF No error messages or diagnos-
tics
–
