turck BL67 - Module Parameters; Base Modules;Pin Assignment

D300529 0115 - BL67 I/O modules
5-49
BL67-16DI-P
5.8.4 Module parameters
none
5.8.5 Base modules/pin assignment
 BL67-B-8M8
Figure 5-70:
0
1
2
4
5
6
3
7
Figure 5-71:
1 = V
SENS
2 = Signal A
3 = GND
4 = Signal B
v
42
31
-4-P
BL67-B-8M8-4-P
Pin assignment
B
L67-16DI-P with
BL67-B-8M8-4-P
