turck BL67 - Process Data Mapping

D300529 0115 - BL67 I/O modules
10-39
BL67-2AI2AO-VI, voltage/current
10.2.2 Process data mapping
n = offset of input data; depending on extension of station and the corresponding fieldbus.
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
Process data Meaning
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Input n
AI0 LSB
n + 1 AI0 MSB
n + 2 AI1 LSB
n + 3 AI1 MSB
Output m AO0 LSB
m + 1 AO0 MSB
m + 2 AO1 LSB
m + 3 AO1 LSB
NOTE
With PROFIBUS, PROFINET and CANopen, the I/O data of this module is localized within the
proce
ss data of the whole station via the hardware configuration tool of the fieldbus master.
For DeviceNet, EtherNet/IP and Modbus TCP a detailed mapping table can be created with
the TURCK configuration tool I/O-ASSISTANT V3 (PACTware + BL67-DTM).
Table 10-6:
Process data bits
AI1 LSB low byte of the analog value
AIx MSB high byte of the analog value
AOx LSB low byte of the analog value
AOx LSB high byte of the analog value
