turck BL67 - Technical Data

Digital input modules
D300529 0115 - BL67 I/O modules5-34
5.6.1 Technical data
Table 5-36:
Technical data
Designation BL67-4DI-N
No. of channels 4
Input voltage V
sens
at nominal value 24 VDC
Low level > 7 V (max. 30 V)
High level < 5 V
Nominal current consumption at
5 VDC (module bus) I
MB
≤ 30 mA
Nominal current from supply terminal (field) I
L
≤ 1 mA (all inputs low)
Power loss of the module < 1,3 W
Input current I
in
Low level < 2,5 mA
High level > 3 mA
Input delay
t
ON
< 250 μs
t
OFF
< 250 μs
Isolation voltage
U
TMB
(module bus/field) max. 2500 VDC
U
FE
max. 1000 VDC
