BL67-16DI-P
5.8.1 Technical data
5.8.2 Process data mapping
n = offset of input data; depending on extension of station and the corresponding fieldbus.
Process data Value Meaning
Table 5-51:
Technical data
Designation BL67-16DI-P
No. of channels 16
Input voltage V
sens
at nominal value 24 VDC
Low level < 4,5 V
High level >
7 V (max.
30 V)
Nominal current consumption from 5 VDC (mod-
ule bus) I
MB
≤ 30 mA
Nominal current from supply terminal (field) I
L
≤ 3 mA (all inputs low)
max sensor supply I
sens
4 A
via gateway or Power Feeding module,
electronically short circuit limited
Power loss of the module < 100 mW
Input current I
in
Low level < 1,5 mA
High level 2,1 to 3,7 mA
Input delay 0.3 ms
Isolation voltage
U
(electronic/field) 500 VDC
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Input n
DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
n + 1 DI15 DI14 DI13 DI12 DI11 DI10 DI9 DI8
NOTE
With PROFIBUS, PROFINET and CANopen, the I/O data of this module is localized within the
proce
ss data of the whole station via the hardware configuration tool of the fieldbus master.
For DeviceNet, EtherNet/IP and Modbus TCP a detailed mapping table can be created with
the TURCK configuration tool I/O-ASSISTANT V3 (PACTware + BL67-DTM).
Table 5-52:
Process data bits
DIx 0 Digital input inactive
1 Digita
l input active
