BL67-4DO-2A-N
7.7.6 Signal assignment
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
C = slot no.
P = pin no.
Table 7-48:
Signal assign-
ment with BL67-B-
4M8
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
Out m - - - - C3P4 C2P4 C1P4 C0P4
Table 7-49:
Signal assign-
ment with BL67-B-
2M12
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
Out m - - - - C1P2 C0P2 C1P4 C0P4
Table 7-50:
Signal assign-
ment with
BL67-B-2M12-P
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
Out m - - - - C1P2 C1P4 C0P2 C0P4
Table 7-51:
Signal assign-
ment with
BL67-B-4M12
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
Out m - - - - C3P4 C2P4 C1P4 C0P4
Table 7-52:
Signal assign-
ment with
BL67-B-1M23
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
Out m - - - - C0P4 C0P3 C0P2 C0P1
