Digital output modules
D300529 0115 - BL67 I/O modules7-38
7.6.2 Process data mapping
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
Proc
ess data Value Meaning
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Output m
DO7 DO6 DO5 DO4 DO3 DO2 DO1 DO0
m DO15 DO14 DO13 DO12 DO11 DO10 DO9 DO8
NOTE
With PROFIBUS, PROFINET and CANopen, the I/O data of this module is localized within the
process data of the whole
station via the hardware configuration tool of the fieldbus master.
For DeviceNet, EtherNet/IP and Modbus TCP a detailed mapping table can be created with
the TURCK configuration tool I/O-ASSISTANT V3 (PACTware + BL67-DTM).
Table 7-38:
Process data bits
DOx 0 Digital output inactive
1 Di
gital output active
