turck BL67 - Module Parameters

D300529 0115 - BL67 I/O modules
9-35
BL67-8XSG-P
9.4.4 Module parameters
NOTE
Due to a product actualization, the parameter texts of the TURCK-I/O-product have been
revised.
The actual configuration files (GSD-, GSDML-, EDS-files) with the new parameters can be
found under www.turck.com.
If you use older configuration files with old parameter texts (issue date before April 2014),
then you can find a cross reference list in the manual's appendix (see Cross reference list
parameters (page 15-30)).
Standard
PROFIBUS/
PROFINET
Parameter
byte-
oriented
word-
oriented
Byte 0
Bit 0
Word 0
Bit 0
Byte 0
Bit 0 Activate input filter (channel 0)
Bit 1 Bit 1 Bit 1 Activate input filter (channel 1)
Bit 2 Bit 2 Bit 2 Activate input filter (channel 2)
Bit 3 Bit 3 Bit 3 Activate input filter (channel 3)
Bit 4 Bit 4 Bit 4 Activate input filter (channel 4)
Bit 5 Bit 5 Bit 5 Activate input filter (channel 5)
Bit 6 Bit 6 Bit 6 Activate input filter (channel 6)
Bit 7 Bit 7 Bit 7 Activate input filter (channel 7)
Byte 1
Bit 0 Bit 8
Byte 1
Bit 0 Invert digital input (channel 0)
Bit 1 Bit 9 Bit 1 Invert digital input (channel 1)
Bit 2 Bit 10 Bit 2 Invert digital input (channel 2)
Bit 3 Bit 11 Bit 3 Invert digital input (channel 3)
Bit 4 Bit 12 Bit 4 Invert digital input (channel 4)
Bit 5 Bit 13 Bit 5 Invert digital input (channel 5)
Bit 6 Bit 14 Bit 6 Invert digital input (channel 6)
Bit 7 Bit 15 Bit 7 Invert digital input (channel 7)
Byte 2
Bit 0
Word 1
Bit 0
Byte 2
Bit 0 Manu. output reset after overcurrent (channel 0)
Bit 1Bit 1Bit 1Manu. output reset after overcurrent (channel 1)
Bit 2Bit 2Bit 2Manu. output reset after overcurrent (channel 2)
Bit 3Bit 3Bit 3Manu. output reset after overcurrent (channel 3)
Bit 4Bit 4Bit 4Manu. output reset after overcurrent (channel 4)
Bit 5Bit 5Bit 5Manu. output reset after overcurrent (channel 5)
Bit 6Bit 6Bit 6Manu. output reset after overcurrent (channel 6)
Bit 7Bit 7Bit 7Manu. output reset after overcurrent (channel 7)
Byte 3
Bit 0
Word 1
Bit 8
Byte 3
Bit 0 Activate output (channel 0)
Bit 1 Bit 9 Bit 1 Activate output (channel 1)
Bit 2 Bit 10 Bit 2 Activate output (channel 2)
Bit 3 Bit 11 Bit 3 Activate output (channel 3)
Bit 4 Bit 12 Bit 4 Activate output (channel 4)
Bit 5 Bit 13 Bit 5 Activate output (channel 5)
Bit 6 Bit 14 Bit 6 Activate output (channel 6)
Bit 7 Bit 15 Bit 7 Activate output (channel 7)
