Building up a BL67 station
13.2 Building up a BL67 station
13.2.1 Mounting the gateway
The gateway is the first electronics component on a BL67 station.
The electronic modules are mounted on the right side of the gateway.
13.2.2 Mounting a base module
1 The module bus contacts of the first base module have to be inserted from above into the module
bus contacts of the gateway.
2 Tighten the screws of the inserted base module.
3 All other base modules of the station are mounted identically. Their module bus contacts have to fit
into the contacts of the respective left-hand base module.
NOTE
The BL67-station should be assembled completely before mounting it on a mounting plate or
a mounting rail.
ATTENTION!
Deficient screwing
Protection class IP67 not guaranteed
 Tighten the screws in the base modules correctly.
ATTENTION!
Damaged sealing
Protection class IP67 not guaranteed
 Check the sealing at the left module bus connector of the base modules for correct fit and
damage.
