turck BL67 - Base Modules;Pin Assignment

D300529 0115 - BL67 I/O modules
5-17
BL67-4DI-PD
5.3.5 Base modules/pin assignment
 BL67-B-4M8
Figure 5-16:
1
0
2
3
Figure 5-17:
3
1
4
v
1 = V
SENS
3 = GND
4 = Input A
Figure 5-18:
3 () BU
1 (+) BN
4 ( ) BK
 BL67-B-2M12/BL67-B-2M12-P
Figure 5-19:
0
1
BL67-B-4M8
Pin assignment
B
L67-4DI-PD with
BL67-B-4M8
Wiring diagram
BL67-4DI-PD with
BL67-B-4M8
BL67-B-2M12/
B
L67-B-2M12-P
