BL67-1RS485/422
12.2.7 Base modules/pin assignment
 BL67-B-1M12
Figure 12-15:
0
/BL67-B-1M12-8
Figure 12-16:
4
1
3
2
5
v
1 = Tx 
2 = Tx +
3 = Rx 
4 = Rx +
5 = Schirm
Figure 12-17:
6
1
3
2
8
v
4
5
7
1 = Rx +
2 = Tx +
3 = Tx 
4 = n.c.
5 = Rx 
6 = GND
ISO
7 = n.c.
8 = Schirm
 BL67-B-1M23
Figure 12-18:
0
/BL67-B-1M23-VI
BL67-B-1M12-8/
BL67-B-1M12
pin assignment
BL67-1RS485/422
with BL67-B-1M12
pin assignment
BL67-1RS485/422
with
BL67-B-1M12-8
BL67-B-1M23/
B
L67-B-1M23-VI
