BL67 components
2.2 BL67 components
Gateway
The gate
way connects the fieldbus to the I/O modules. It is responsible for handling the entire process
data and generates diagnostic information for the higher-level master and the software tool I/O-
ASSIS-TANT (PACTware + BL67-DTM).
Figure 2-2:
Figure 2-1:
BL67 station PRO-
FIBUS-DP
A PBDP-
gateway
B electronic
module
C Base module
BL67 gateway
for PROFIBUS-
DP
A
B
C
