BL67-16DO-0.1A-P
7.6.1 Technical data
Table 7-37:
Technical data
Designation BL67-16DO-0.1A-P
No. of channels 16
Nominal voltage from supply terminal 24 VDC
Load voltage V
O
24 VDC
Voltage range 18 to 30 VDC
Nominal current consumption from 5 VDC
(module bus) I
MB
≤ 30 mA
Nominal current from supply terminal (field) I
L
< 100 mA (if load current = 0)
Power loss of the module, typical < 1,5 W
Output voltage, high level (loaded) min. L+ (-1 V)
Output current I
A
High level
A
(nominal value) 0.1 A
High level I
AMAX
0.12 A (according to IEC 61131-2)
Simultaneity factor 100 % (at I
MAX
≤ 120 mA),
50 % (at I
MAX
≤ 180 mA)
Delay at signal change and resistive load
from low to high level 3 ms
from high to low level 3 ms
Load impedance range 250 Ω to 10 kΩ
Switch-on resistance R
on
max. 2 Ω
Resistive, inductive and lamp loads can be connected
Load impedance, resistive R
LO
250 Ω
Switching frequency
resistive load 200 Hz
inductive load 2 Hz
Isolation voltage
U
TMB
(module bus/field) max. 2500 VDC
U
FE
(field/functional earth) max. 1000 VDC
Short-circuit proof yes, according to EN 61 131-2
