8.3.5 Base modules/pin assignment
 BL67-B-2M12
Figure 8-7:
0
1
Figure 8-8:
4
1
3
2
5
v
1 = V
SENS
2 = AO +
3 = GND
4 = AO 
5 = PE
8.3.6 Measurement value representation
16-bit-representation
 Voltage values from 0 to 10 VDC
The value range:
0 V to 10 V
is displayed as follows:
0000
hex
to 7FFF
hex
(decimal: 0 to 32767)
 Voltage values from -10 to 10 V DC
The value range:
0 V to 10 V
is displayed as follows:
0000
hex
to 7FFF
hex
(decimal: 0 to 32767)
The value range:
-10 V to -3,052 10
-4
V
is displayed as follows:
8000
hex
to FFFF
hex
(decimal:-32768 to -1)
BL67-B-2M12
Pin assignment
B
L67-2AO-I with
BL67-B-2M12
