Digital input modules
D300529 0115 - BL67 I/O modules5-10
5.2.6 Signal assignment
n = process data offset in input data; depending on
extension of station and the corresponding fieldbus
C = slot no.
P = pin no.
Table 5-5:
Signal assign-
ment with BL67-B-
4M8
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n - - - - C3P4 C2P4 C1P4 C0P4
Table 5-6:
Signal assign-
ment with BL67-B-
2M12
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n - - - - C1P2 C0P2 C1P4 C0P4
Table 5-7:
Signal assign-
ment with BL67-B-
2M12-P
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n - - - - C1P2 C1P4 C0P2 C0P4
Table 5-8:
Signal assign-
ment with BL67-B-
4M12
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n - - - - C3P4 C2P4 C1P4 C0P4
Table 5-9:
Signal assignment
with BL67-B-1M23
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n - - - - C0P4 C0P3 C0P2 C0P1
