General technical data
3.5 General technical data
ATTENTION!
Disregarding the SELV-range
Destruction of components
The auxiliary power supply must comply with the stipulations of SELV (Safety Extra Low
Voltage) according to IEC 60364-4-41.
Table 3-3:
General
technical data
Supply voltage/auxiliary voltage
Demands on the voltage supply acc. to EN 61131-2
Nominal value (provision for other modules) 24 VDC
Permissible range according to EN 61131 -2 18 to 30 VDC
Residual ripple according to EN 61131-2
Potential isolation yes, via opto-coupler
Isolation voltages
–Fieldbus/(V
I
/V
O
)
– PROFIBUS-DP: 500 V
eff
– DeviceNet: none
– Ethernet: 500 V
eff
–V
I
/V
O
none
–(V
I
/V
O
1)/(V
I
/V
O
2), with PF module for poten-
tial isolation
500 V
eff
–Fieldbus/(V
I
/V
O
2) 500 V
eff
Ambient conditions
Ambient temperature
–t
Ambient
0 to +55 °C/32 to 131 °F
–t
Store
-25 to +85 °C/-13 to 185 °F
Relative humidity according to IEC 61131 -2
Climatic tests according to EN 61131 -2
Noxious gas according to IEC 68068-42/43
Resistance to vibration according to IEC 61131 -2
Protection class according to IEC 60529
IP67
Shock resistant according to IEC 61131 -2
Topple and fall/free fall according to IEC 61131 -2
Emitted interference
High-frequency, radiated according to EN 55011, Class A
Immunity to interference
