D300529 0115 - BL67 I/O modules
5-35
BL67-4DI-N
5.6.2 Process data mapping
n = offset of input data; depending on extension of station and the corresponding fieldbus.
Process data Value Meaning
5.6.3 Diagnostic and status messages
LED status displays
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Inputn----DI3DI2DI1DI0
NOTE
With PROFIBUS, PROFINET and CANopen, the I/O data of this module is localized within the
proce
ss data of the whole station via the hardware configuration tool of the fieldbus master.
For DeviceNet, EtherNet/IP and Modbus TCP a detailed mapping table can be created with
the TURCK configuration tool I/O-ASSISTANT V3 (PACTware + BL67-DTM).
Table 5-37:
Process data bits
DIx 0 Digital input inactive
1 Digita
l input active
Table 5-38:
LED status dis-
plays
LED Display Meaning Remedy
D Red Module bus communication
failure
Check if more than two
ad-joining
electronics modules have been
pulled. This concerns modules
located between this module and
the gateway.
OFF No error messages
0 to 3 Green Status of channel x = "1"
OFF Status of channel x = "0" -
