Digital combi modules
D300529 0115 - BL67 I/O modules9-40
9.4.6 Signal assignment
n = Offset of process input data; depending on extension of station and the corresponding fieldbus.
m = Offset of process output data; depending on extension of station and the corresponding fieldbus.
C = slot no.
P = pin no.
9.4.7 Sensor supply
Table 9-26:
Signal assign-
ment with BL67-B-
8M8
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n C7P4 C6P4 C5P4 C4P4 C3P4 C2P4 C1P4 C0P4
Out m C7P4 C6P4 C5P4 C4P4 C3P4 C2P4 C1P4 C0P4
Table 9-27:
Signal assign-
ment with BL67-B-
4M12
Data Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n C3P2 C2P2 C1P2 C0P2 C3P4 C2P4 C1P4 C0P4
Out m C3P2 C2P2 C1P2 C0P2 C3P4 C2P4 C1P4 C0P4
Table 9-28:
Signal assign-
ment with BL67-B-
4M12-P
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n C3P2 C3P4 C2P2 C2P4 C1P2 C1P4 C0P2 C0P4
Out m C3P2 C3P4 C2P2 C2P4 C1P2 C1P4 C0P2 C0P4
Table 9-29:
Signal assign-
ment with BL67-B-
1M23
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
In n C0P8 C0P7 C0P6 C0P5 C0P4 C0P3 C0P2 C0P1
Out m C0P8 C0P7 C0P6 C0P5 C0P4 C0P3 C0P2 C0P1
Table 9-30:
Sensor supply
V
sens
ABCD
BL67-B-8M8 C0P1/
C1P1
C2P1/
C3P1
C4P1/
C5P1
C6P1/
C7P1
BL67-B-4M12 C0P1 C1P1 C2P1 C3P1
BL67-B-4M12-P C0P1 C1P1 C2P1 C3P1
BL67-B-1M23 C0P9 C0P10 C0P11 -
