turck BL67 - Measurement Value Representation of the Inputs

D300529 0115 - BL67 I/O modules
10-11
BL67-4AI4AO-VI, voltage/current
10.1.5 Measurement value representation of the inputs
Standard value representation
 16-bit-representation
-10 … 10 V bipolar Diagnostics dec. hex.
voltage value U
M
= (dec. value × 3,052 × 10
-4
) V
> 10.1000 V
at ↑ DIA Measured value out
of range
ON
32767 7FFF
≤ 10.0500 V
at ↓ DIA Measured value out
of range
OFF
32767 7FFF
10.0000 V
nominal range
32767 7FFF
9.9997 V 32766 7FFE
………
5.0002 V 16384 4000
………
0.000305 V 1 0001
0.000000 V 0 0000
-0.000305 V -1 FFFF
………
-5.0000 V -16384 C000
………
-9.9997 V -32767 8001
≤ -10.0000 V -32768 8000
≥ -10,0500 V
at ↑ DIA Measured value out
of range
OFF
-32768 8000
< -10,1000 V
at ↓ DIA Measured value out
of range
ON
-32768 8000
0 … 10 V unipolar Diagnostics dec. hex.
voltage value U
M
= (dec. value × 3,052 × 10
-4
) V
> 10.1000 V
at ↑ DIA Measured value out
of range
ON
32767 7FFF
≤ 10.0500 V
at ↓ DIA Measured value out
of range
OFF
32767 7FFF
10.0000 V
nominal range
32767 7FFF
9.9997 V 32766 7FFE
………
5.0002 V 16384 4000
………
0.000305 V 1 0001
≤ 0.000000 V 0 0000
≥ -0,0500 V
at ↑ DIA Measured value out
of range
OFF
00000
< -0,1000 V
at ↓ DIA Measured value out
of range
ON
00000
