turck BL67 - Base Modules;Pin Assignment

D300529 0115 - BL67 I/O modules
7-9
BL67-4DO-0.5A-P
7.2.5 Base modules/pin assignment
 BL67-B-4M8
Figure 7-3:
1
0
2
3
Figure 7-4:
3
1
4
v
1 = V
SENS
3 = GND
4 = Output A
Figure 7-5:
1 BN
+24 VDC
4 (+) BK
3 () BU
 BL67-B-2M12/BL67-B-2M12-P (paired)
Figure 7-6:
0
1
BL67-B-4M8
Pin assignment
BL67-4DO-0.5A-P
with BL67-B-4M8
Wiring diagram
B
L67-4DO-0.5A-P
with BL67-B-4M8
BL67-B-2M12/
BL67-B-2M12-P
