turck BL67 - Page 174

Figure 7-7:
4
1
3
2
5
v
1 = V
SENS
2 = Output B
3 = GND
4 = Output A
5 = PE
Figure 7-8:
4 (+) BK
3 () BU
2 (+) WH
5
Digital output modules
D300529 0115 - BL67 I/O modules7-10
 BL67-B-4M12
Figure 7-9:
1
2
3
0
Figure 7-10:
4
1
3
2
5
v
1 = V
SENS
2 = n.c.
3 = GND
4 = Output A
5 = PE
Figure 7-11:
3 () BU
4 ( ) BK
5
Pin assignment
BL67-4DO-0.5A-P
with BL67-B-2M12/
BL67-B-2M12-P
Wiring diagram
B
L67-4DO-0.5A-P
with
BL67-B-2M12/
BL67-B-2M12-P
BL67-B-4M12
Pin assignment
BL67-4DO-0.5A-P
with BL67-B-4M12
Wiring diagram
BL67-4DO-0.5A-P
with BL67-B-4M12
